SG40 2 Post Lift Manual release Base plate lift 4 ton SG40
R35,950.00
Centre plate between the 2 post to cover the hydraulic pipes and steel synchronizing ropes.
It is the most common type of lift, but the plate can be considered an obstruction when removing gearboxes on a transmission jack, however this lift is suitable for low ceiling workshops.
Model: SG40
Product: 4 Ton manual release – Base plate
*Colours and designs may differ
Technical information
Lift
Lifting capacity: 4000kg
Maximum lifting height: 1900mm
Minimum lifting height: 85mm
Overall height: 2826mm
Overall width: 3426mm
Width between columns: 2803mm
Maximum vehicle width: 2775mm
Lifting time: 40s
Lowering time: 60s
Noise level: 70 dB(A0/1m
Average weight of package: 620kg
Did you like this product? Add to favorites now and follow the product.

Description
Centre plate between the 2 post to cover the hydraulic pipes and steel synchronizing ropes.
It is the most common type of lift, but the plate can be considered an obstruction when removing gearboxes on a transmission jack, however this lift is suitable for low ceiling workshops.
Model: SG40
Product: 4 Ton manual release – Base plate
*Colours and designs may differ
Technical information
Lift
Lifting capacity: 4000kg
Maximum lifting height: 1900mm
Minimum lifting height: 85mm
Overall height: 2826mm
Overall width: 3426mm
Width between columns: 2803mm
Maximum vehicle width: 2775mm
Lifting time: 40s
Lowering time: 60s
Noise level: 70 dB(A0/1m
Average weight of package: 620kg
Features and Benefits
| Features: | Benefits: |
| Manual release | When you have a power outage, the locks can still be released to lower the vehicle. |
| Floor plate design | Suitable for low ceiling workshop, and the height is not limited by an overhead beam. The lift can accommodate tall vehicles, roof racks and other roof-mounted features. |
| Cables | Stainless steel, strong and corrosion resistant. |
| Double cylinders | High strength chain drive system |
| Dynamic test 115% of the rate capacity | Ensures the hoist works correctly through its full cycle of operation |
| Static test: 150% of the rated capacity | Static load testing, to unsure the lifts can handle the recommended tonnage. Safety test. |
| Dual anti skidding safety device from column ladder to hydraulic seal protection | If the hydraulic system fails for some reason the vehicle on the lift will not fall, the lifts safety locks will lock into place to prevent any accidents. |
| Hydraulic system | Designed to avoid overload running |
| ABS control box, 24v low voltage control system | Conforms to ISO standards and electrical components of the lift. |
| High quality seals from Italy | Seals can withstand high pressure and mechanical stress. |
| Quality power rack | Ensures safety at all heights. |
| Conforms to CE requirements | The CE Mark on a product or machine identifies it as complying with all the of safety requirements established by the European Union. |
| Faster Service: The use of a hoist speeds up the service process, reducing the time customers need to wait for their vehicles to be ready. This can lead to higher customer satisfaction and retention.Quality Service: Mechanics can perform more comprehensive inspections and repairs when a vehicle is on a hoist, ensuring that customers receive a higher quality of service Increased Efficiency: Versatility: Enhanced Reputation: Improved Safety: Productivity: Space Efficiency: Competitive Advantage: Long-Term Investment: | |
| Training available | Technicians can be professionally trained to use the machine and get the maximum benefit from it. |
| 1 year warranty | The machine will be repaired if there are any factory faults and can be replaced if required. |
| Spares available | Should you have a breakdown you will not have to wait for your machine to be repaired. If there is anything we don’t have, we fly it in directly from the Suppliers. |
